• PLC with HMI allows simple operation.
• Auto Positioning of Article ( Optional ).
• Electronic foil controller especially for taper containers.
• Vaccum to hold & auto blow ejecting systems.
• A highly precise photo sensor is used to monitor and control the feeding of foil with Dots.
• Special provisions are made to avoid damage to the silicone roller in case of power failure.
• All machined components are coated for long-term protection.
• All major Electric components are from reputed make like Siemens, Selec, Panasonic, SPG, etc.
• All major Pneumatic components are from reputed make like Festo & Janatics.
| Parameter | HTL 3000 | HTL 3000F |
|---|---|---|
| Application | For Round Articles | For Flat Articles |
| Maximum Print Size | 400mm dia X 285mm Height | 300mm dia X 250mm Height |
| Power Requirement | 3.5 KW /230 V AC, 50Hz | 3.5 KW /230 V AC, 50Hz |
| Air Pressure | 5 kg/cm2 | 5 kg/cm2 |
| Machine Dimension | (L)1270 X (W)1400 X (H)2030 | (L)1270 X (W)1400 X (H)2030 |
| Weight | 550 kg | 550 kg |
